1600 Litre Sewage Pumping Station - 6 Meter Lift

RAX1600L - 1600 Litre Sewage Pumping Station – Reliable Domestic Wastewater Management - Fully Packaged

Suitable for domestic and commercial use

The 1600 Litre Single Rigged Sewage Pumping Station is a complete packaged solution designed for sites where gravity drainage is not possible. Wastewater is collected in a durable underground chamber and then pumped directly to the main sewer. Suitable for both foul water (sewage) and surface water applications, this system is manufactured to BSEN752-6 standards and provides up to 24 hours of emergency storage, ensuring dependable performance in demanding conditions.

Ideal for Domestic, Commercial & Industrial Use

The Single Rigged 1600 system is designed for small to large homes, commercial buildings, and industrial environments where the drainage level sits below the main sewer or septic tank. Engineered for quick installation, the station arrives with all internal components pre-fitted—only external pipework and fittings need to be supplied.
Each unit features a robust submersible pump with 50 mm solids handling, offering reliable and clog-resistant operation.

Key Applications

This high-capacity 1600L pump station is suitable for a wide range of installations, including:

• Large residential properties

• Commercial premises

• Industrial buildings

• Offices and professional environments

• Agricultural applications

Pump Specifications

• Cast iron and stainless steel construction

• 50 mm (2") solids handling capacity

• Coolant-filled motor for improved durability

• Mechanical seal for long-term reliability

• 10 m power cable

• Maximum lift: 6 metres (Need more lift? -  Select to upgrade)

• Maximum flow: 5 L/sec

• Float switch included as standard

• 1 × 10 m float control

Tank Specifications

• Heavy-duty polyethylene tank

• Dimensions: 1.2 m² × 1.5 m

• Capacity: 1600 litres

• 110 mm inlet seal for on-site drilling

• 40 mm cable duct

• 2" internal pipework

• 2" non-return valve

• 2" quick-release coupling

• 2" cable duct


Everything can be delivered in a single shipment, ensuring you have everything needed for a hassle-free setup.
